E1000-16P+4CF

COMMANDO Scout E1000 16FE + 2GE + 2SFP Uplink, 260W PoE+, Smart Switch

Click on image to expanded

E1000-16P+4CF

COMMANDO Scout E1000 16FE + 2GE + 2SFP Uplink, 260W PoE+, Smart Switch

COMMANDO Scout E1000, 16 10/100 Fast Ethernet Ports, 4 Combo port, 2GE + 2SFP Uplink, 30W PoE Per Port, 260W PoE Power Budget, 6KV Thunder Protection, 7.2Gbps Bandwidth, 5.36Mpps Packet Forwarding, 8K MAC, 4.1Mb Buffer, 10K bytes Jumbo Frames, 16MB FLASH, Plug-and-play, Auto MDI/MDI-X, Auto-negotiation, Auto-sensing, Unmanaged Smart Switches

Information

E1000-16P+4CF 16 10/100M + 2 10/100/1000M + 2 SFP Uplink Ports, 260W PoE+, 30W Per Port PoE Budget, 6KV Thunder Protection, Auto MDI/MDIX, Flood Control: Full-duplex: IEEE 802.3x, Half-duplex: back pressure, Plug and Play, Self-Adaption, Support Standard, Port Isolation.

Scout E1000 Series Smart Unmanaged Switch

COMMANDO Scout E1000 Smart Switch is an ideal unmanaged Switch, Designed for Small and Medium Business Networks that require Plug & Play Network Switch. To optimize traffic on your Business Network, COMMANDO offers Port-based/802.1p/DSCP QoS to keep Latency-sensitive traffic moving smoothly and jitter-free. Additionally, port-based, tag-based and MTU VLAN can improve security and meet more network segmentation requirements. Moreover, with its innovative energy-efficient technology, COMMANDO Switch can save up to 58% of power consumption, making it an eco-friendly solution for your business network

IEEE 802.3af/at Compliant Power over Ethernet

The Scout E1000 PoE series supports IEEE 802.3af/at Compliant PoE and has a total power supply range from 260W~530W to power any 802.3af/at compliant power device. It’s an efficient and cost-effective choice to work with wireless access points, surveillance cameras, IP phones and other PoE supported devices, while getting rid of cables or power lines running around. Compact and flexible, C1000 series is ideal to flexibly use PoE to deploy wireless access points or IP-based network surveillance cameras for projects or small business networks.

Specification

Hardware
ModelE1000-16P+4CF
Port16 10/100M
Uplink2 10/100/1000M
2 SFP
Reset1
PoE+260W
PoE Per Ports30W Max
Bandwidth7.2Gbps
Packet Forwarding5.36Mpps
MAC8K
Buffer4.1M
Jumbo Frames10Kbytes
FLASH16M
TransmissionStore and forward
Thunder Protection6KV
EnvironmentalOperating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~95% non-condensing
Power inAC 180-240V 50/60Hz
Fan QuantityFan less
Dimensions ( W x D x H )232*152*45 mm
CertificationCE, FCC
Standards ProtocolsIEEE 802.3
IEEE 802.3i 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3x
System ModelDefault standard,Port isolation
SpeedEthernet 10Mbps half-duplex, 20Mbps full-duplex
Fast Ethernet 100Mbpshalf-duplex, 200Mbps full-duplex
Gigabit Ethernet 2000Mbps full-duplex
Network Media10Base-T: Pair 2 Category 3(Cat3) and above UTP/STP(<=150m)
100Base-TX: Pair 2 Category 5(Cat5) and above UTP/STP(<=150m)
1000Base-T: Pair 4 Category 5(Cat5e) and above UTP/STP(<=150m)
Product SpecificationsWidth 17.3 in (440 mm)
Depth 7.95 in (202 mm)
Height 1.45 in (44 mm)
Weight 4.59 lb (2.08 kg)
