E1000-48P+4CF

COMMANDO Scout E1000 48FE + 2GE + 2SFP Uplink, 530W PoE, Smart Switch

E1000-48P+4CF

COMMANDO Scout E1000 48FE + 2GE + 2SFP Uplink, 530W PoE, Smart Switch

E1000-48P+4CF 48 10/100M + 2 10/100/1000M + 2 SFP Uplink Ports, 530W PoE+, 30W Per Port PoE Budget, 6KV Thunder Protection, Auto MDI/MDIX, Flood Control: Full-duplex: IEEE 802.3x, Half-duplex: back pressure, Plug and Play, Self-Adaption, Support Standard, Port Isolation.

Scout E1000 Series Smart Unmanaged Switch

COMMANDO Scout E1000 Smart Switch is an ideal unmanaged Switch, Designed for Small and Medium Business Networks that require Plug & Play Network Switch. To optimize traffic on your Business Network, COMMANDO offers Port-based/802.1p/DSCP QoS to keep Latency-sensitive traffic moving smoothly and jitter-free. Additionally, port-based, tag-based and MTU VLAN can improve security and meet more network segmentation requirements. Moreover, with its innovative energy-efficient technology, COMMANDO Switch can save up to 58% of power consumption, making it an eco-friendly solution for your business network

IEEE 802.3af/at Compliant Power over Ethernet

The Scout E1000 PoE series supports IEEE 802.3af/at Compliant PoE and has a total power supply range from 260W~530W to power any 802.3af/at compliant power device. It’s an efficient and cost-effective choice to work with wireless access points, surveillance cameras, IP phones and other PoE supported devices, while getting rid of cables or power lines running around. Compact and flexible, C1000 series is ideal to flexibly use PoE to deploy wireless access points or IP-based network surveillance cameras for projects or small business networks.

Hardware
Model E1000-48P+4CF
Port 48 10/100M
Uplink 2 10/100/1000M
2 SFP
Reset  1
PoE+ 530W
PoE Per Ports 30W Max
Bandwidth 8.8Gbps
Packet Forwarding 6.55Mpps
MAC 8K
Buffer 4.1M
Jumbo Frames 10Kbytes
FLASH 16M
Transmission Store and forward
Thunder Protection 6KV
Environmental Operating Temperature: 0℃ ~40℃ (32 ℉ ~104 ℉ )
Storage Temperature: -40℃ ~70℃ (-40 ℉ ~158 ℉ )
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~95% non-condensing
Power in AC 100~240V 50/60hz
Fan Quantity Fan less
Dimensions ( W x D x H ) 232*152*45 mm
Certification CE, FCC
Standards Protocols IEEE 802.3
IEEE 802.3i 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3x
System Model Default standard,Port isolation
Speed Ethernet 10Mbps half-duplex, 20Mbps full-duplex
Fast Ethernet 100Mbpshalf-duplex, 200Mbps full-duplex
Gigabit Ethernet 2000Mbps full-duplex
Network Media 10Base-T: Pair 2 Category 3(Cat3) and above UTP/STP(≤150m)
100Base-TX: Pair 2 Category 5(Cat5) and above UTP/STP(≤150m)
1000Base-T: Pair 4 Category 5(Cat5e) and above UTP/STP(≤150m)
Product Specifications Width 17.3 in (440 mm)
Depth 7.95 in (202 mm)
Height 1.45 in (44 mm)
Weight 4.59 lb (2.08 kg)
