IE1000-8GP+2SFP

COMMANDO Soldier 1000 8GE + 2SFP Uplinks, 96W PoE, Web Managed Industrial Ethernet Switch

COMMANDO Soldier IE1000 Smart Web Managed Industrial Ethernet Switch is an ideal upgrade from an unmanaged Switch, Designed for Small and Medium Business Networks that require simple Network Management. The Configuration is largely simplified by Web Based user Interface. Network Administrators can effectively monitor traffic via Port Mirroring, Loop Prevention and Cable Diagnostics features. To optimize traffic on your Business Network, COMMANDO offers Port-based/802.1p/DSCP QoS to keep Latency-sensitive traffic moving smoothly and jitter-free. Additionally, port-based, tag-based and MTU VLAN can improve security and meet more network segmentation requirements. Moreover, with its innovative energy-efficient technology, COMMANDO Switch can save up to 58% of power consumption, making it an eco-friendly solution for your business network

Easy to Use

COMMANDO Soldier IE1000 Series switch is easy to use and manage. Auto MDI/MDI-X crossover on all RJ45 ports eliminate the need for crossover cables or uplink ports. Auto-negotiation on each port senses the link speed of a network device (10, 100, or 1000 Mbps) and intelligently adjusts for compatibility and optimal performance. Its compact size makes it ideal for desktops with limited space. Dynamic LED lights provide real-time work status display and basic fault diagnosis.

IEEE 802.3af/at Compliant Power over Ethernet

The Soldier IE1000 PoE series supports IEEE 802.3af/at Compliant PoE and has a total power supply range from 45W~96W to power any 802.3af/at compliant power device. It’s an efficient and cost-effective choice to work with wireless access points, surveillance cameras, IP phones and other PoE supported devices, while getting rid of cables or power lines running around. Compact and flexible, C1000 series is ideal to flexibly use PoE to deploy wireless access points or IP-based network surveillance cameras for projects or small business networks.

Effective Management

COMMANDO offers Network Monitoring for users to observe traffic behavior. You can easily configure it by the web-based user interface. With Port Mirroring, Loop Prevention and DHCP snooping features, COMMANDO can identify and even locate connection problems on your business network. Moreover, administrators can designate the priority of the traffic based on Port Priority, 802.1P and DSCP Priority, to ensure that voice and video are always clear, smooth and lag-free. Additionally, to improve security and network performance, COMMANDO supports MTU VLAN, port-based VLAN and 802.1Q-based VLAN functions. COMMANDO is an upgrade from the plug-and-play Unmanaged Switch, delivering great value while empowering your network and similarly delivering great value to the end user.

Go Green with Your Ethernet

You now have the choice to go green when upgrading to a gigabit network! This new generation COMMANDO Gigabit Smart Switch features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status and cable length to limit the carbon footprint of your network.

Power down Idle Ports

When a computer or network equipment is off, the corresponding port of a traditional switch will continue to consume considerable amounts of power. The COMMANDO can automatically detect the link status of each port and reduce the power consumption of ports that are idle.

Power Budget According to Cable Length

Ideally, shorter cables would use less power because of less power degradation over their length; this is not the case with most devices as they will use the same amount of power across the cable regardless of whether it is 10 or 50 meters in length. The COMMANDO analyzes the length of the Ethernet cable connected and adjusts the power usage accordingly, rather than keeping the power consumption in a conventional solution.

Hardware
Model IE1000-8GP+2SFP
Port
8 10/100/1000M
2 SFP
Reset KEY 1
PoE+ 96W
PoE Per Ports 30W Max
Bandwidth 20Gbps
Packet Forwarding 14.88Mpps
MAC 8K
Buffer 4.1M
Jumbo Frames 10Kbytes
FLASH 16M
Transmission Store and forward
Thunder Protection 6KV
Environmental
working temperature : 0℃~50℃
Storage temperature : -40℃~70℃
Operating humidity : 10%~90% Non coagulation
Storage humidity : 5%~95% Non coagulation
Power in AC 100~240V 50/60hz
WEB software function
Standards
IEEE 802.3x
IEEE 802.3,IEEE 802.3u,IEEE 802.3ab,IEEE 802.3z
IEEE 802.3ad
IEEE 802.3q ,IEEE 802.3q/p
IEEE 802.1w, IEEE 802.1d, EEE 802.1S
IEEE 802.1w,IEEE 802.1d, EEE 802.1S
Port Auto-MDIX ; Auto Negotiation
MAC Address 8K MAC addresses ;MAC address learning and aging
VLAN 4k VLANS;Port-based VLANs;802.1Q VLAN
Spanning Tree
STP(Spanning Tree Protocol)
RSTP/MSTP( Rapid Spanning Tree Protocol)
EPPS ring network protocol
EAPS ring network protocol
802.1x argumentation agreement
Link Aggregation
Max 8 aggregation groups, each supports 8 ports
Static aggregation and dynamic aggregation
Port Mirror Many-to-one port mirroring
Loop Guard Loop protection function, real-time detection, rapid alarm, accurate positioning, intelligent blocking, automatic recovery
Port flow control
Half duplex based back pressure control
Full duplex based on PAUSE frames
IGMP Snooping
IGMPv1/2/3 and MLDv1/2 Snooping
GMRP protocol registration
Multicast address management, multicast VLAN, multicast routing ports, static multicast addresses
DHCP DHCP Snoping
Storm suppression
Unknown unicast, multicast, unknown multicast, storm suppression of broadcast type
Storm suppression based on bandwidth tuning and storm filtering
Storm suppression
Unknown unicast, multicast, unknown multicast, storm suppression of broadcast type
Storm suppression based on bandwidth tuning and storm filtering
Security
User port+IP address+MAC
ACL based on IP and MAC
Security properties of port based MAC address quantities
QOS
802.1p port queue priority algorithm
Cos/Tos,QOS sign
WRR (Weighted Round Robin),Weighted priority rotation algorithm
WRR,SP,WFQ,3 priority scheduling models
system maintenance
Upgrade package upload;system log view
WEB restore factory configuration
Management and maintenance HTTP/HTTPS (SSL v2/3 TLS) Web based GUI
