SG100-5

COMMANDO SG100, 4GE + 1GE Uplinks, Smart Unmanaged Switch

Click on image to expanded

SG100-5

COMMANDO SG100, 4GE + 1GE Uplinks, Smart Unmanaged Switch

Information

SG100-5 Gigabit switch, mainly for the Ethernet access layer or aggregation layer, Plug and play, self-adaption, support standard, Store-and-forward, port isolation 2 working modes.


Main Features
  • 5 10/100/1000M Rj45 network
  • Support camera, wireless AP, and IP phone etc.
  • Flood Control: Full-duplex: IEEE 802.3x, Half-duplex: back pressure.
  • Auto MDI/MDIX.
  • Support port lightning protection.
  • Store-and-forward.
  • All ports support wire speed switch, jumbo frame transmission.
  • Plug and play, self-adaption.
  • Panel lights can monitor operative mode and malfunction analysis.

Specification

Hardware
ModelSG100-5
Port5 10/100/1000M Rj45
Exchange MechanismStore-and-forward
Bandwidth10G
MAC1K
EnvironmentalWorking Temperature: 0°C~40°C
Storage temperature: -40°C~70°C
Working Humidity: 10%~90% RH non-condensing
Storage Humidity: 5%~90% RH non-condensing
Power inputDC 5~15V
Standards ProtocolsIEEE 802.3
IEEE 802.3i 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3x
IEEE 802.1q
System modelDefault standard, Port isolation
SpeedEthernet 10Mbps half-duplex, 20Mbps full-duplex
Fast Ethernet 100Mbpshalf-duplex, 200Mbps full-duplex
Gigabit Ethernet 2000Mbps full-duplex
Network Media10Base-T: Pair 2 Category 3(Cat3) and above UTP/STP(<=150m)
100Base-TX: Pair 2 Category 5(Cat5) and above UTP/STP(<=150m)
1000Base-TX: Pair 4 Category 5(Cat5e) and above UTP/STP(<=150m)
Product specificationsProduct Size: 132mm*88mm*32mm(L*W*H)
package Size: 300mm*208mm*58mm(L*W*H)
Weight: 0.5Kg
