AIR-AP1800AX

COMMANDO AirONE 1800Mbps, 2.4GHz+5GHz, 802.11ax/ac/b/g/n, Wave 2.0, Wi-Fi 6 Access Point

Data Sheet Config Guide Gallery YouTube

AIR-AP1800AX

COMMANDO AirONE 1800Mbps, 2.4GHz+5GHz, 802.11ax/ac/b/g/n, Wave 2.0, Wi-Fi 6 Access Point

Product Highlights

Multiple Operational Modes like Gateway Mode, AP mode (Default mode is AP mode).
Multi SSID up to 8 with inbuilt WI-FI channel analysis.
Supports IEEE 811ax/ac/b/g/n with backward compatibility for wireless clients, 2.4GHz+5GHz Wireless dual band with radio RF Power up to 300mW .
Support wireless RF power adjustable as per user movements from AP with data rate up to 1800Mbps.
Access end users up to 256 max, with concurrent end users up to 120+.
Supports band steering automatically move to wider 5G band for faster connections, intelligent load balance based on users.
Support tag VLAN and VLAN management.
Supports advance security by MAC ACL, Static DHCP, Flow control, URL Mapping, IP/MAC/URL filters, Port mapping and DMZ.
Support Seamless Roaming, OFDMA, 1024-QAM.
Dual purposes WAN or IEEE 802.3at Port (PoE+) port supporting 1x 10/100/1000Mbps and dedicated LAN ports 1x 10/100/1000Mbps.
Supports Wi-Fi client distance 91 meters and above depending on surrounding conditions.
Dual input for power either PoE+ via WAN port or DC power inputs 12V, 2A.
Support Open or encryption like WPA/WPA2PSK_TKIPAES.
With best-in-class power amplifier and FEM, Build in 3dBi MIMO Antenna for stronger signal strength & supports large wireless coverage (91m and above) in all directions.
Comply with IEEE 802.3az standard
Plug and Play design simplifies installation with self-adaption.
Compact, silent design perfect for noise sensitive environments.
With Zero Touch Provisioning: Plug and play and no setup. Affordable, Easy-to-Use AP for all sized business networks, with Zero Configuration Required.
Built-in High-Performance Processor with Flash: SPI NOR 32MB , and 256MB RAM which greatly improved the data processing performance. Suitable for Deployment of Large Scale Commercial Scenarios
Comes with one-year default warranty – optionally extendable up to 3 years.

Software Highlights


Home

Device Information like CPU Usage, Memory Usage, LAN Information like IP Mode Get IP From AC/Gateway/Static, Status with 2G/5G Wi-Fi, Clients Status with information like SSID, Channel, Bandwidth, Encrypt, MAC Address, Operation Mode configure like AP/ Fat AP Mode with Uptime, Flow in bps for AP Downstream and AP Up stream.

Wizard

Gateway Mode, AP Mode (Default Selection).

Wi-Fi

2G/5G Wi-Fi with Basic and VAP (1 to 3) ON/OFF with Wi-Fi Analyzer, SSID, Hide your SSID, Bandwidth, Channel, Encryption Open/Encryption with WPA/WPA2PSK_TKIPAES, MAC ACL with Add, Delete, Apply with disable/Allow/Prohibit option, Wi-Fi Timer OFF/ON with Time Frame, Advanced setting like Country Region, 2G/5G Channels, Country Region, User Isolation, Short GI, Coverage Threshold, Packet Threshold, RTS Threshold and DFS.

Network

LAN Settings with DHCP server option, Static DHCP, Cloud Server Settings.

Firewall

URL Filter, IP Filter, MAC Filter, Port mapping and DMZ.

Manage

Configure, Reboot, Modify Password, Upgrade, Time, Log, Flow Control, IP Group, Time Group and DDNS.

https://www.commandonetworks.com//AIR-AP1800AX
1
How to Install and Configure Wi-Fi 6 Wireless Access Point - COMMANDO AirONE AIR-AP1800AX 1800Mbps
16 Jan 2023
Data Sheet
Config Guide
Gallery
YouTube
