4 in 1 Operation Mode Wireless AP, Gateway, Wireless Bridge & Super WDS, Supports HI-MAX TDMA Technology, Support Multi SSID up to 4, Support Beamforming Technology, MIMO High Gain Omni 18dBi Internal Antenna, 802.11ac, 2T2R 900M MIMO Technology, 16MB Flash, 128M DDR2 RAM, Support 24V Passive PoE
AIR-CPE10K+ is a 900Mbps outdoor wireless CPE/Bridge, Build in 15dBi Omni antenna, 10KM+ Outdoor Wi-Fi Distance Coverage. It supports Wireless AP, Gateway, Wireless Bridge & Super WDS Operation Mode, effective solution for outdoor Wi-Fi coverage application. With an outdoor waterproof and dustproof enclosure, built in lighting protection IC, support 24V passive PoE, 2T2R 900M MIMO Technology, 900Mbps high speed, integrated IEEE 802.3af PoE Power over Ethernet (PoE), it can be installed in areas where power outlets are not readily available.
900Mbps outdoor wireless CPE/Bridge
4 in 1 Operation Mode Wireless
Support Multi SSID up to 4
Supports PTP/PTMP Distance up to 10KM.
Support WDS PTP/PTMP connection by LED display configuration
AIR-CPE10K+ Supports HI-MAX TDMA Technology (use polling technique to solve the hidden node and resource waste problem between the CPE and base station, provide low latency, high throughput in PTP/PTMP application likes IP camera, long range Wi-Fi Transmission), Gateway, Wireless AP, WISP, WDS operation mode for all wireless coverage.
900Mbps High Data Rate, High Performance
AIR-CPE10K+ support Wireless AP, Gateway, Wireless Bridge, super WDS operation mode, to suit for variety application environment. LED display, easy to setup IP address, signal strength, Channel and WDS connection by Function/Selection switch together with LED display, no need to access into GUI, avoid the complex setup program, save much human work and cost, make the long range wireless coverage, data transmit and wireless monitoring simple and professional.
Time-division multiple access
Time-division multiple access (TDMA) is a channel access method for shared-medium networks. It allows several users to share the same frequency channel by dividing the signal into different time slots The users transmit in rapid succession, one after the other, each using its own time slot. This allows multiple stations to share the same transmission medium (e.g. radio frequency channel) while using only a part of its channel capacity
Power over Ethernet (PoE)
IEEE 802.3af Power over Ethernet (PoE), work with standard PoE switch, 24V passive PoE Integrated, Plug and Play, installed in areas where power outlets are not readily available, eliminating the mess of altering existing network infrastructure.
Multiple Operation Mode for Multiple Application
Support Wireless AP, Gateway, Wireless Bridge & Super WDS to meet with different installation requirements, such as Gateway for home use, Wi-Fi Repeater to extend the exist Wi-Fi signal to more range
802.11ac/a/n standard, 2X2 900Mbps MIMO Technology
1 * 10/100/1000Mbps WAN Port 1 * 10/100/1000Mbps LAN Port 1*Reset Button for restore factory default settings 1*DC power Port 1*WDS Switch button to do PTP/PTMP connection
18dBi directional antenna
Power,wifi,WAN,LAN, Signal Strength
DC 12V/1A;24V PoE Power
Transmission Data rate
IEEE 802.11ac IEEE 802.11n IEEE 802.11a
Intelligent Channel Analysis Distance Controll 802.1x ACK Time Output Virtual SSID up to 4 BSSID
WEP Encryption-64/128/152 bit WPA/WPA2 Personal Encryption (WPA-PSK using TKIP or AES) WPA/WPA2 Enterprise Encryption (WPA-EAP using TKIP) High SSID
Web-based configuration (HTTP/Telnet)
Upgrade firmware via web browser or TFTP
Admin User name/Password can be configured
Device and Networking status statistic
Support local log, host log, log file exporting
Reset to factory defaults
Backup device configuration, then restore this configuration if need
Working Temperature: -20°C~55°C Storage Temperature: -40°C ~ 70°C
Working Humidity 5%~95% RH No condensation Storage Humidity 5%~95% RH No condensation
