COMMANDO AirPRO 8KM, 300Mbps, 5GHz, 802.11n, 10dBi, 27dBm, 2×2 MIMO, Cloud Wireless Bridge
AIR-WB5G-8K-PRO
COMMANDO AirPRO 8KM, 300Mbps, 5GHz, 802.11n, 10dBi, 27dBm, 2×2 MIMO, Cloud Wireless Bridge
COMMANDO AirPRO Series Outdoor Wireless Bridge Access Point, Cloud Based, 300 Mbps, Multimode Operation,5GHz(300Mbps), 802.11a/n, 2×2 MIMO 10dBi Internal Antenna, 8 MB Flash, 64 MB RAM, PoE Enable
Information
AIR-WB5G-8K-PRO is a Wi-Fi Bridge Point to Point Outdoor Wireless Access Point, comply with IEEE 802.11a/n technology, uses 2×2 MIMO high-performance processor technology and an industrial-grade Qualcomm chip solution to provide higher-speed, longer-distance wireless link transmission than ever before, and externally powered by PoE. The longest outdoor transmission distance can reach more than 8 kilometers. long-distance monitoring and construction is convenient, saving engineering costs and maintaining maintenance. Suitable for wireless monitoring of elevators, hanging towers, construction sites, terminals, factories, driving schools, schools, oil fields, scenic spots, etc.
Features
300Mbps High Data Rate, High PerformanceAIR-WB5G-8K-PRO supports AP, Wireless Client, AP Repeater, Mesh to suit for variety application environment. Avoid the complex setup program, save much human work and cost, make the long range wireless coverage, data transmit and wireless monitoring simple and professional.
Time-division multiple accessTime-division multiple access (TDMA) is a channel access method for shared-medium networks. It allows several users to share the same frequency channel by dividing the signal into different time slots The users transmit in rapid succession, one after the other, each using its own time slot. This allows multiple stations to share the same transmission medium (e.g. radio frequency channel) while using only a part of its channel capacity
Power over Ethernet (PoE)IEEE 802.11a/n Power over Ethernet (PoE), work with standard PoE switch, 24V passive PoE Integrated, Plug and Play, installed in areas where power outlets are not readily available, eliminating the mess of altering existing network infrastructure.
Specification
| Hardware | |
|---|---|
| Wireless | IEEE 802.11 a/n, 300Mbps MIMO Technology |
| Interface | 1* 10/100Mbps WAN Port 1* 10/100Mbps LAN Port 1* Reset Button to restore factory default |
| Antenna | 10dBi MIMO Internal Antenna |
| Power | PoE: IEEE 802.11 a/n, 48V |
| Size | 260*100*60mm |
| Data rate | 300Mbps |
| Firmware | |
| Operation mode | AP, Wireless Client, AP Repeater, Mesh |
| Network Protocol | IEEE 802.3(Ethernet) IEEE 802.3u(Fast Ethernet) IEEE802.11 a/n IEEE802.11a/n |
| Wireless Setting | Support TDMA Support multiple SSID Support WEP encryption |
| Wireless Security | WEP Encryption-64/128/152 bit WPA/WPA2 Personal Encryption (WPA-PSK using TKIP or AES) WPA/WPA2 Enterprise Encryption (WPA-EAP using TKIP) High SSID |
| System Setting | Web-based configuration (HTTP/Telnet) |
| Firmware upgrade | Upgrade firmware via web browser or TFTP |
| Administration Management | Admin User name/Password can be configured |
| System monitoring | Device and Networking status statistic |
| System Log | Support local log, host log, log file exporting |
| Reset | Reset to factory defaults |
| Backup | Backup device configuration, then restore this configuration if need |
