AIR-AP1300

COMMANDO AirONE 1300Mbps, 2.4GHz+5GHz, 802.11ac, Wave 2.0, MU-MIMO, Enterprise Access Point

Config Guide Gallery YouTube

AIR-AP1300

COMMANDO AirONE 1300Mbps, 2.4GHz+5GHz, 802.11ac, Wave 2.0, MU-MIMO, Enterprise Access Point

Product Highlights

• Multiple Operational Modes like Gateway Mode, Repeater mode, WISP mode, AP mode (Default mode is AP mode).

• Multi SSID up to 8 with inbuilt WI-FI channel analysis.

• Supports IEEE 802.11ac/b/g/n 2.4GHz+5GHz Wireless which having dual band with radio RF Power up to 26dBm.

• Support wireless RF power adjustable as per user movements from AP.

• Access end users up to 128 max, with concurrent end users up to 100.

• Support tag VLAN and VLAN management.

• Supports intelligent load balance based on users.

• Support seamless roaming and low-rate terminal access.

• Dual purposes WAN or IEEE 802.3at Port (PoE+) port supporting 1x 10/100/1000Mbps and dedicated LAN ports 1x 10/100/1000Mbps.

• Supports Wi-Fi client distance 91 meters and above depending on surrounding conditions.

• Dual input for power either PoE+ or DC power inputs 12V, 1.5A.

• Support Open or encryption like WPA/WPA2PSK_TKIPAES.

• Plug and Play design simplifies installation with self-adaption.

• Compact, silent design perfect for noise sensitive environments.

• With Zero Touch Provisioning: Plug and play and no setup. Affordable, Easy-to-Use AP for Small Business Networks, with Zero Configuration Required.

• Built-in High-Performance Processor with long life, Suitable for Deployment of Large Scale Commercial Scenarios

• Comes with one-year default warranty – optionally extendable up to 3 years.

Software Highlights

Home

Device Information like CPU Usage, Memory Usage, LAN Information like IP Mode Get IP From AC/Gateway/Static, Status with 2G/5G Wi-Fi, Clients Status with information like SSID, Channel, Bandwidth, Encrypt, MAC Address, Operation Mode configure like AP/ Fat AP Mode with Uptime, Flow in bps for AP Downstream and AP Upstream

Wizard

Gateway Mode, Repeater Mode, WISP Mode, AP Mode (Default Selection)

Wi-Fi

2G/5G Wi-Fi with Basic and VAP (1 to 3) ON/OFF, SSID, Hide your SSID, Bandwidth, Channel, Encryption Open/Encryption with WPA/WPA2PSK_TKIPAES, MAC ACL with Add, Delete, Apply with disable/Allow/ Prohibit option, Wi-Fi Timer Off/ON with Time Frame, Advanced setting like Country Region, 2G/5G Channels, Multicast Fast, Maximum clients for AP, WLAN Partition, Short GI, Coverage Threshold(-95dBm~-65dBm), TX Power, DFS.

Network

LAN Settings with DHCP server option, Static DHCP, VLAN Settings, Cloud Server Settings

Manage

Configure, Reboot, Modify Password, Upgrade, Time, Log

https://www.commandonetworks.com//AIR-AP1300

COMMANDO Networks - 0 / 0

Wireless AirX Outdoor AIR-APO1200 and AIR-APO3000AX AirX Configuration Guide

17 Apr 2025

AIR-WB900-10K --COMMANDO AirX 900M 5.8GHz 17dBi MU-MIMO 802.11ac Wave2 P2P/P2MP 10KM Wireless Bridge

01 Mar 2025

AIR-WB900-5K -- COMMANDO AirX 900Mbps 5.8GHz 14dBi 802.11ac P2P/P2MP, 5KM Enterprise Wireless Bridge

01 Mar 2025

AIR-WB450-3K -- COMMANDO AirX 450Mbps 5.8GHz 12dBi 802.11ac P2P/P2MP, 3KM Enterprise Wireless Bridge

01 Mar 2025

AIR-WB450-1K -- COMMANDO AirX 450Mbps, 5.8GHz 8dBi 802.11ac P2P/P2MP, 1KM Enterprise Wireless Bridge

01 Mar 2025

How to Install and Configure Wireless Bridge - COMMANDO AirONE AIR-WB-1K / AIR-CPE1K+, 802.11n

03 Feb 2023

How to Install and Configure Wireless Bridge - COMMANDO AirONE AIR-WB5G-10K / AIR-CPE10K+, 900Mbps

03 Feb 2023

How to Install and Configure Wireless Bridge - COMMANDO AirONE AIR-CPE10K+ / AIR-WB5G-10K, 900Mbps

01 Feb 2023

How to Install and Configure Ceiling Wireless Access Point - COMMANDO AirONE AIR-AP750 750M 802.11ac

01 Feb 2023

How to Install and Configure Cloud Wireless Access Point - COMMANDO AirPRO AIR-AP1200-PRO Dual Radio

24 Jan 2023

How to Install and Configure Ceiling Wireless Access Point - COMMANDO AirONE AIR-AP300, 802.11n

23 Jan 2023

How to Install and Configure Wi-Fi 6 Wireless Access Point - COMMANDO AirONE AIR-AP1800AX 1800Mbps

16 Jan 2023

Config Guide

Gallery

YouTube

Click on image to expanded

AIR-AP1300

COMMANDO AirONE 1300Mbps, 2.4GHz+5GHz, 802.11ac, Wave 2.0, MU-MIMO, Enterprise Access Point

Price & Availability:

{"highlights":"<div><span>\u2022<\/span> Multiple Operational Modes like Gateway Mode, Repeater mode, WISP mode, AP mode (Default mode is AP mode).<\/div>\r\n<div><span>\u2022<\/span> Multi SSID up to 8 with inbuilt WI-FI channel analysis.<\/div>\r\n<div><span>\u2022<\/span> Supports IEEE 802.11ac\/b\/g\/n 2.4GHz+5GHz Wireless which having dual band with radio RF Power up to 26dBm.<\/div>\r\n<div><span>\u2022<\/span> Support wireless RF power adjustable as per user movements from AP.<\/div>\r\n<div><span>\u2022<\/span> Access end users up to 128 max, with concurrent end users up to 100.<\/div>\r\n<div><span>\u2022<\/span> Support tag VLAN and VLAN management.<\/div>\r\n<div><span>\u2022<\/span> Supports intelligent load balance based on users.<\/div>\r\n<div><span>\u2022<\/span> Support seamless roaming and low-rate terminal access.<\/div>\r\n<div><span>\u2022<\/span> Dual purposes WAN or IEEE 802.3at Port (PoE+) port supporting 1x 10\/100\/1000Mbps and dedicated LAN ports 1x 10\/100\/1000Mbps.<\/div>\r\n<div><span>\u2022<\/span> Supports Wi-Fi client distance 91 meters and above depending on surrounding conditions.<\/div>\r\n<div><span>\u2022<\/span> Dual input for power either PoE+ or DC power inputs 12V, 1.5A.<\/div>\r\n<div><span>\u2022<\/span> Support Open or encryption like WPA\/WPA2PSK_TKIPAES.<\/div>\r\n<div><span>\u2022<\/span> Plug and Play design simplifies installation with self-adaption.<\/div>\r\n<div><span>\u2022<\/span> Compact, silent design perfect for noise sensitive environments.<\/div>\r\n<div><span>\u2022<\/span> With Zero Touch Provisioning: Plug and play and no setup. Affordable, Easy-to-Use AP for Small Business Networks, with Zero Configuration Required.<\/div>\r\n<div><span>\u2022<\/span> Built-in High-Performance Processor with long life, Suitable for Deployment of Large Scale Commercial Scenarios<\/div>\r\n<div><span>\u2022<\/span> Comes with one-year default warranty \u2013 optionally extendable up to 3 years.<\/div>","sub_category":"Ceiling AP","one_line_des":"COMMANDO AirONE 1300Mbps, 2.4GHz+5GHz, 802.11ac, Wave 2.0, MU-MIMO, Enterprise Access Point","part_code":"AIR-AP1300"}

Product Highlights : View Details

Hardware
Standard	802.11ac/b/g/n, MU-MIMO technology
Memory	512MB DDR3 RAM
Flash	32MB
Interface	1 * 10/100 /1000Mbps RJ45 WAN Port 1 * 10/100 / 1000Mbps RJ45 LAN Port 1 * Reset button, press 10 seconds to revert to default setting 1*DC Port
Antenna	Build in 3dBi MIMO Antenna
Power consumption	48V PoE<30W
Size	198mm X 32mm
RF Data
Frequency	2.4G:802.11b/g/n: 2.4GHz – 2.484GHz 5GHz:802.11a/n/ac MIMO: 5.150GHz~5.850GHz
Country code	FCC, IC, ETSI, MKK, MKK1, MKK2, MKK3, NCC, RUSSIAN, CN
Modulation	OFDM = BPSK,QPSK, 16-QAM, 64-QAM, 128-QAM, 256-QAM DSSS = DBPSK, DQPSK, CCK
Throughput	1300Mbps
2.4G RF Power (IPQ4019)	802.11b: 11M 23±2dBm, 1M 25±2dBm 802.11g: 54M 22±2dBm, 6M 24±2dBm 802.11n HT20: MCS7 21±2dBm, MCS0 23±2dBm 802.11n HT40: MCS7 21±2dBm, MCS0 23±2dBm
5G RF Power(IPQ4019)	802.11b: 54M 19±2dBm, 6M 21±2dBm 802.11n HT20: MCS7 18±2dBm, MCS0 20±2dBm 802.11n HT40: MCS7 18±2dBm, MCS0 20±2dBm 802.11ac HT80: MCS9 17±2dBm, MCS0 19±2dBm
2.4G Receive Sensitivity	802.11b: 11M -85dBm, 1M -94dBm 802.11g: 54M -72dBm, 6M -90dBm 802.11n HT20: MCS7 -70dBm, MCS0 -88dBm 802.11n HT40: MCS7 -68dBm, MCS0 -86dBm
5G Receive Sensitivity	802.11b: 54M -72dBm, 6M -90dBm 802.11n HT20: MCS7 -70dBm, MCS0 -88dBm 802.11n HT40: MCS7 -68dBm, MCS0 -86dBm 802.11ac HT80: MCS9 -58dBm, MCS0 -85dBm
EVM	2.4G EVM: 802.11b: <=-10 dB; 802.11g: <=-25 dB; 802.11n: <=-28dB 5G EVM: 802.11a: <=-25 dB; 802.11n: <=-28 dB; 802.11ac: <=-32 dB
PPM	±20ppm
Max Users	128
Firmware Features
Operation mode	Wireless AP, Gateway, WISP, Wi-Fi Repeater
WAN Type	Dynamic IP/Static IP/PPPoE/L2TP(Dual Access) /PPTP(Dual Access)
Wireless Security	64/128-bit WEP, WPA / WPA2, WPA-PSK/ WPA2-PSK encryption
SSID	12 Multiple SSID (4 SSID for 2.4G, 8 SSID for 5.8G)
Firewall	DoS, SPI Firewall, IP Address Filter/MAC Address Filter/Domain Filter IP and MAC Address Binding
Protocols	IPv4
Others
Package Contents	COMMANDO Dual Band 1300Mbps Wireless Access Point Ethernet Cable Quick Installation Guide Setting Accessory
System Requirements	Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, Windows 8, MAC OS, NetWare, UNIX or Linux
Environment	Operating Temperature: -20~55°C Limit working temperature: -30~70°C Storage Temperature: -40~70°C Humidity: 5%~95% non-condensing
Management	Firmware GUI , Remote Management, WLAN Controller, Cloud Management System
