AIR-AP3600BE

COMMANDO AirPRO 3600Mbps, 1x2.5Gbps, PoE & DC, Wi-Fi 7, Cloud Indoor Access Point

Data Sheet Gallery YouTube

AIR-AP3600BE

COMMANDO AirPRO 3600Mbps, 1x2.5Gbps, PoE & DC, Wi-Fi 7, Cloud Indoor Access Point

Product Highlights

• Cloud Managed 4x4 Indoor Wi-Fi 7 Access Point

• Dual Radio Access Point (2.4 GHz/5 GHz) , 4x4 MIMO stream for IEEE802.11be (Wi-Fi 7) operation greatly improves communication efficiency.

• Up to 3.6 Gbps 2.4GHz(688Mbps) & 5GHz(2882Mbps)

• Equipped with 1*2.5Gbps Port, dual purposes IEEE 802.3at Port (PoE+) port supporting 1x 10/100/1000/2500Mbps.

• Wi-Fi 7 standard supports ultra-wide 320 MHz channels that can deliver extreme throughput and provides greater network capacity.

• 4-MU-MIMO, 4096-QAM, which increase overall performance, reliability, and high-density device support by utilizing multiple bands, avoiding interference, and reducing latency.

• Cutting-edge COMMANDO Cloud for centralized management and mass scalability.

• Access point monitoring with COMMANDO controller and COMMANDO Cloud for real-time remote monitoring and troubleshooting.

• FAT mode support multiple operational modes like AP, routing mode (Default mode is FIT-AP mode).

• Multi SSID up to 8 with inbuilt Wi-Fi channel analysis.

• Management with the help of WEB GUI, COMMANDO Controller & from Cloud portal.

• Supports IEEE 802.11be/ax/ac/a/b/g/n with backward compatibility for wireless clients, 2.4GHz+5GHz Wireless dual band.

• Built-in 5dBi MIMO Antenna with wireless RF power adjustable as per user movements from AP.

• Access end users up to 130+.

• Supports band steering automatically move to wider 5G band for faster connections, intelligent load balance based on users.

• Supports Wi-Fi client distance 35 meters and above depending on surrounding conditions.

• Dual input for power either PoE+ via WAN/LAN port or DC power inputs 12V, 2A.

• Support Open or encryption like WPA3, WPA/WPA2PSK_TKIPAES.

• With the function of the built-in firewall, IP filter, URL filter, and MAC filter.

• Comply with IEEE 802.3az standard.

• Plug and Play design simplifies installation with self-adaption.

• Compact, silent design perfect for noise sensitive environments.

• With Zero Touch Provisioning with plug and play and no setup. Affordable, Easy-to-Use AP for all sized business networks, with Zero Configuration Required.

• Comes with one-year default warranty – optionally extendable up to 3 years.

Software Highlights

Monitoring

Interface, Terminal, Protocol, Policy, System, Flow Control.

System Setup

Basic Setting, Disk management, Cloud Account, Advanced Settings like ALG Set, Administration, Upgrading, Reboot.

Network

Interfaces, DHCP, DNS, IP/MAC Group, Static Routes, VLAN,VPN Client,UPNP NAT, Port Mapping, IPv6, IGMP Agent.

Flow Control

Multi-WAN features Load Balancing/Protocol/Port Forward/Domain Name/Upload/Download, Smart Flow Control, IP/MAC Limiters, Protocol Library.

Access Controller

Wireless overview, AP Configuration, AP group, AP Firmware Upgrades, Wireless black and white list, User Information.

1. Wireless overview: Open Access Controller with ON/OFF button. The connected AP will automatically enter the AP device list and can Manage AP. Running State of AP status with Online AP, Offline AP, fast roaming, 5G first along with terminal statistics like 2.4G online, 5G online, peak online, active terminal, inactive terminal. Wireless Network Rating with traffic statistics, terminal association details with Access evaluation, Access times, Average access success rate with Network transmission quality.

2. AP Configuration: Access Point Configuration with All groupings, All Status like Online/Offline/Upgrading, All Frequency like (2.4G/2.4G+5G) and IP/MAC/Model/Remarks.

Interference Analysis with Start Searching AP, MAC, Remarks, BSSID, BSSID Remark, SSID, Signal Value, Channel along with Import or Export configuration files.

Default Configuration for 2.4G, 5G Radio with other Setting like SSID1 Name - COMMANDO01

SSID1 Security No Password, SSID1 VLAN Close, Hide SSID1 Name Open, SSID rate limit Open, Guest Mode Open (Isolate guest devices discovery and access to wired network) Channel Auto, AP Signal 80% default Channel width 20 MHz can change to 40MHz or self-adaptation, Airtime scheduling, Advanced settings like Beacon frame power

Follow AP signal strength Beacon frame interval 200 ms, RTS threshold0, Low-rate access license Allow all, Management frame rate 1Mbps.

3. AP group: AP Group Add/Delete with Group name, Number of AP, channel, Maximum belt capacity, SSID, Actions. With Add button click we can set Group name with 2.4G/5G control state information.

4. AP Firmware Upgrades: Access Point Upgrades with MAC/Model, Upgrade All, Batch Upgrade with information like MAC Address, Current Version, Latest Version, Status, AP Remarks, Actions

5. Wireless black and white list: With Add, Import, Export, Enable, Disable, Delete which also shows Mode, Terminal MAC address, SSID, AP, week, time, comment, Status, Actions

6. User Information: User Information with IP/MAC/SSID, All Frequency (2.4G/5G), All users along with weak signal users and normal users showing information like IP Address, MAC, AP Information, SSID, Signal, Connect Time, Tx, Rx, Comment, Actions.

Authentication

Captive Portal, VPN Server, Authentication Account, Push Notification.

Behaviour

Behavior Audit with Mark MAC Address, MAC Control, Website Control, URL Control, Application Protocol Control, Secondary Routing, QQ, Blacklist/Whitelist.

Firewall

ACL Rules, ARP binding, Connection Limiter, Advanced Firewall. Advanced application-->Dynamic DNS, SNMP, Application across three layers, Wake on LAN, FTP Server, HTTP Server, UDPXY Set.

Services

Ping Test, Capture Packet, Trace Route, IP Sub-netting, Speed Test, Diagnostics, Watchdog.

Log

User Logs, Function Logs, System Logs.

COMMANDO AirPRO Ceiling AP’s controller also has cloud captive portal with AirPRO Cloud Login http://commandonetworks.com.cn/#/login.
