MC-GSMSF-25K

COMMANDO LightningFIBER 1GE, Single Mode, Single Fiber, 1310/1550nm, 25KM, MC

Data Sheet Gallery YouTube

MC-GSMSF-25K

COMMANDO LightningFIBER 1GE, Single Mode, Single Fiber, 1310/1550nm, 25KM, MC

Product Highlights

Capable of Gigabit Ethernet connections and provide 1000mbps of data transferring Ethernet RJ45 to SFP Media Converter and vice a versa.
Auto MDI/MDI-X for copper port 10/100/1000Mbps auto-negotiation for copper port along with Half or full duplex auto-negotiation.
Complies with IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z.
Extend network distance up to 25km.
SC single fiber port connector with single mode fiber operating at 1310/1550nm.
Support Link Fault Pass Through function
2048-entry MAC address table with 4-way hash algorithm
Supports 9216-byte jumbo packet length forwarding
Built-in function of broadcast storm suppression, traffic control, CRC error verification
EMC Support, Anti Electro-Static Discharge and Radiation Resistant
Class 1 FDA Laser Safety
Full-duplex and half-duplex operation with IEEE 802.3x flow control along with backpressure
Latest optical module technology with plug and play, reduce & lower optical loss
Compensate for optical power attenuation and provides no packets loss
Automatic identification of MDI/MDI-X and cross connections
Diagnostic LEDs for continuous monitoring real-time network status
Supports SPANNING TREE for loop free networks
Power Adapter External DC 5V, 1A with Wide voltage input design, supporting 5 to 12V external adapters
Compact and durable metallic casing with side vent silent design, perfect for noise sensitive environments
Plug and Play design simplifies installation with self-adaption. Easy Installation with no setup with Zero Configuration Required
Competitive and Affordable price with Inbuilt SFP and RJ-45 Port which saves cost. Easy-to-Use Media Converter for Small Business Networks
A wide range of single-channel Media Converters, suitable for expanding any network depending on the speed and distance of the cable length
Works in harsh environment with heat dissipation optimization
Supports Energy-Efficient Ethernet(EEE) function (IEEE 802.3az)
CE, FCC, ROHS, Lead-Free & ISO 9001:2005
Environmental Specifications for Operating Temperature: 0°C~50°C and Humidity: 5%~90% Non-condensing
Comes with one-year default warranty – optionally extendable up to 3 years with 3 years replacement guarantee
